The devices Quadro IP65 and IP67 are leading solutions in asset tracking, industrial, designed to offer accuracy, durability and performance in any environment. Maximizes your control over your resources.
Specifically designed for the tracking of assets, models Quadro IP65 and Quadro V2 IP67 offer robust solutions and reliable to ensure the visibility and total control of your operations.
Both devices work by using tracking technology advanced that integrates with the online platform of Affortech. Once installed on your assets, the devices send location data and real-time status to the platform, where you can monitor, analyze and optimize the management of your resources from anywhere.
Powerful Microcontroller and dual-core memory with a capacity of +35,000 positions
GNSS (GPS, GLONASS, GALILEO, SBAS)
LBS (4G/2G)
WiFi
BLE 5.0
Network BLE MESH (Supported)
Temperature Accuracy: ± 0.5 C: Range -20°C to 80°C
Humidity ± 2% Accuracy of humidity
Brightness
Vibration/Movement Up to 16G G-forces
LTE Cat1 4G/2G or Cat-M/NB-IoT. with SIM global integrated for use in more than 190 countries, BLE 5 for short-range communication such as iBeacon or Gateway (Secondary)
Choose the appropriate device for your specific needs is crucial. Affortech offers two solutions of tracking the leaders in its class: Quadro IP65 and Quadro V2 IP67. Both devices are designed to provide a precise tracking and reliable, but each one has unique characteristics that make them ideal for different applications and environments. Below, we present a detailed comparison that highlights the three main differences between these two devices, to help you make the best decision according to your operational needs.
Uses a battery module 3xAA, which makes it ideal for applications of short and medium duration. Suitable for operations that require a monitoring intermittent without the need for a long-lasting battery.
Dimensions of 65x65x29mm, designed for installations in tight spaces where size is a critical factor.
Ideal for environments that are less demanding, which does not require extreme resistance to water or dust.
Equipped with a battery designed for more than 10 years of use, reporting once a day, which makes it perfect for applications that require continuous monitoring for the long term.
IP67 rating, which means it is completely dust-tight and water resistant (can be submerged up to 1 meter for 30 minutes), making it ideal for harsh environments.
Dimensions of 72x65x34mm, a little larger than the IP65, offering greater durability and protection in extreme conditions.
